Loncin LC1P70FC Engine 22mm 196cc
$379.00
Air Cleaner Semi-dry, dual element
Bore x Stroke 70mm x 51mm
Net power 3.5 kW/3600rpm
Net torque 10.5 Nm./2500rpm
Idle speed 2200 +/- 150 rpm
Compression ratio 7.11
PTO shaft rotation Anti-clockwise(from PTO side)
Lubrication system Splash
Dimensions 385 x 358 x 278mm
Crankshaft 7/8" (22.2mm) 3/8-24 UNF keyed
Fuel consumption <=395g/kWh
Valve clearance input valve0.10-0.15mm, output valve0.15-0.20mm
Spark plug clearance 0.7~0.8mm
Displacement 196cc
Engine type Single cylinder, 4 stroke, forced cooling ,OHV
Starting system Recoil start
Ignition system Transistorized magneto ignition
Net weight 12.8kg
